This HDMI Scaler is designed to scale 4K (and non-4K) HDMI signals to resolutions of
1080p/WUXGA or lower while also simultaneously bypassing the 4K signal to a 4K native
display. With its friendly and simple OSD (On Screen Display) interface design this unit
allows the user to easily change output resolutions and related video settings directly from
the front panel. This scaler is the ideal product for expanding the capabilities of your 4K
UHD media environment.
- 1 HDMI Giriş
- 1 Bypass Çıkış
- 1 Scaler Çıkış
- 4K Giriş >> 4K + 1080p Çıkış
- 1080p Giriş >> 1080p + 1080p Çıkış
- HDMI, HDCP ve DVI uyumluluk
- HDMI 4K2K signal bypass desteği
- Eş zamanlı 2 HDMI çıkışı
- Features on-screen display (OSD) menüsü ile ayarlar
- Kullanımı kolay arayüz
Girişler
- 1x HDMI [1x Uncompressed AV and Data]
- 1x USB Type A [1x SERVICE 1 Propriety Data]
- 1x USB Mini B [1x SERVICE 2 Propriety Data]
Çıkışlar
- 2x HDMI [2x SCALER / BYPASS Uncompressed AV and Data]
Power:
Ölçüler
- 45mm [W] x 167mm [D] x 30mm [H]
Ağırlık
• 1×HDMI to Dual HDMI 4K UHD Scaler
• 1×5V/2.6A DC Power Adaptor
• 1×Operation Manual
